Vertiv™ | Liebert® SRC-G | User Manual 1
Overview
Chapter 1: Overview
This chapter introduces the model description, product introduction, basic parameters, main components,
optional components, and ambient requirements of Vertiv™ Liebert® SRC-G Precision air conditioner
(hereafter Liebert SRC-G).
1.1. Product Introduction
The Liebert SRC-G is first of its kind innovative product with ‘zero’ footprint due to its wall mounted configuration.
The Liebert SRC-G is a small precise environment control system, specially designed for cooling the equipment
rooms. It is applicable in equipment rooms, computer rooms and similar eco-system. Featuring high reliability, it
can maintain a favorable environment for critical equipment such as sensitive equipment, industrial processing
equipment, communication equipment, and computers.
Liebert SRC-G is dedicatedly design to fit into small technological rooms. It is a wall mounted type unit, which has
maximum cooling capacity with nearly no footprint that helps in saving maximum space within equipment rooms.
It is specifically designed for easy serviceability from the front and sides of the unit. The unit design ensures even
air distribution in the small critical infrastructures.
1.1.1. Indoor Unit
Liebert® SRC-G has three models, Liebert® SRC03GES with 3 kW (0.9 TR), Liebert SRC07GES, Liebert
SRC07GET with 7 kW (2 TR), and Liebert SRC11GET with 11 kW (3.1 TR) cooling capacity respectively. Customers
can flexibly select the options according to the actual requirement of the equipment room.
No. Description No. Description
1 Top Mounting Bracket 5 Return air panels
2 Return air perforation 6 Panel hinges
3 Refrigerant in/out and Drain connections 7 SRC cabinet
4 Supply air grills
Figure 1-1 Liebert® SRC-G Indoor Unit
