Vertiv™ | Liebert® SRC-G | User Manual
16
Mechanical Installation
2.4. Mechanical Installation
2.4.1. Dimension and Weight of the Indoor Unit (Product Dimension)
The maintenance space of Liebert® SRC-G models are given in Figure 2-5 and dimensions of models SRC03GES,
SRC07GES, SRC07GET and SRC11GET are depicted in Figure 2-6. Table 2-1 represents maintenance space of the
all indoor units and Table 2-2 represents dimension and operational weight of the all indoor units.
No. Description No. Description
1 Liebert SRC Indoor Unit 2 Maintenance Space
Figure 2-5 Maintenance Space of Liebert SRC-G Model
