Vertiv Liebert SRC-G Series User Manual

Vertiv™ | Liebert® SRC-G | User Manual 9
Overview
1.6. Environmental Conditions Requirements
1.6.1. Operating Environment Requirements
The operating environment requirements for Liebert® SRC-G are given in Table 1-4.
Table 1-4 Operation Environment Requirements
Item Requirements
Installation position
The maximum equivalent horizontal distance between indoor and outdoor units
[1]
: 60 m;
Vertical distance ΔH
[2]
: -5 m ≤ ΔH ≤ 30 m
Installation mode
Indoor unit: horizontal airflow mode (Wall mounted);
Outdoor unit: horizontal airflow mode
Ambient condition
range
Indoor: 21 °C to 30 °C/45% RH to 55% RH
Outdoor: -15 °C to +45 °C (standard model) (it can sustain up to 48 °C outside ambient
temperature)
Altitude < 1000 m, derating is required when location altitude is above 1000 m
Operating Power
range
SRC03GES: 1P, 230 V± 10%, 50 Hz ± 5%
SRC07GES: 1P, 230 V± 10%, 50 Hz ± 5%
SRC07GET: 3P, 400 V± 10%, 50 Hz ± 5%
SRC11GET: 3P, 400 V± 10%, 50 Hz ± 5%
1. For the equivalent lengths of components, refer to Table 2-8.
2. The value of ΔH is positive, if the outdoor unit is installed above the indoor unit; ΔH is negative, if the indoor
unit is installed above the outdoor unit.
1.6.2. Storage Environment Requirements
The storage environment meets the requirements of GB/T 4798.1-2005 and the requirements are listed in
Table 1-5.
Table 1-5 Storage Environment Requirements
Item Requirements
Storage environment Clean indoor without dust
Ambient humidity 5% RH to 95% RH
Ambient temperature -25 °C to +55 °C (transport environment temperature: -40 °C to +70 °C)
Storage time
Total transportation and storage time should not exceed six months, otherwise the
performance of the system needs to be re-calibrated.
