Vertiv™ | Liebert® SRC-G | User Manual 8
Overview
1.5. Additional Components (Optional)
1.5.1. Remote Monitoring
Vertiv™ Liebert® SRC-G series adopts the SNMP communication protocol; through the configured LAN port.
The Liebert SRC-G can communicate with the host computer and receives the control instructions of the host
software.
1.5.2. Installation Accessories
The Liebert SRC-G unit is recommended to be installed with accessories as per Table 1-3.
Table 1-3 Supplied Accessories for Dierent Models
Name of Item SRC03GES SRC07GES SRC07GET SRC11GET
Gas (Suction) pipe
pipe 1/2” with
insulation
5/8” with insulation 5/8” with insulation 7/8” with insulation
Liquid (Discharge) pipe 3/8” with insulation 3/8” with insulation 3/8” with insulation 3/8” with insulation
Indoor power cable 3C x 1.5 mm
2
3C x 1.5 mm
2
3C x 1.5 mm
2
3C x 1.5 mm
2
Fan control cable 3C x 0.5 mm
2
4C x 0.5 mm
2
4C x 0.5 mm
2
5C x 0.5 mm
2
Outdoor power cable* 2C x 2.5 mm
2
2C x 2.5 mm
2
4C x 2.5 mm2 4C x 2.5 mm
2
Fan and contactor 4C x 0.5mm2
Outdoor HP & LP cable 3C x 0.5 mm
2
Outdoor pressure
sensor cable
3C x 0.5mm
2
All field cables are recommended as armored cables in order to avoid external influence such as rat bite etc.
