Mechanical Installation
2.5. Dimension and Weight of the Outdoor Unit
The dimensions of outdoor unit models SRC03GES, SRC07GES, SRC07GET, and SRC11GET are depicted in
Figure 2-7 and Table 2-3 represents dimensions and weight of the all outdoor units.
Figure 2-7 Liebert SRC-G Outdoor Unit Model
Table 2-3 Mechanical Parameters of Outdoor Units
Model
Dimensions (W × D × H)
Operational
Weight (kg)
mm
SRC03GES 970 x 410 x 610 70
SRC07GES 970 x 410 x 800 85
SRC07GET 970 x 410 x 800 85
SRC11GET 970 x 410 x 1170 95
