Vertiv™ | Liebert® SRC-G | User Manual 38
Electrical Installation
3.4. Outdoor Unit Connection
Figure 3-3 shows the location of outdoor cable connection terminal. Figure 3-4 and Figure 3-5 show the amplified
connection terminals for SRC07GES and SRC07GET respectively.
No. Description
1 Outdoor terminal block
Figure 3-3 Outdoor Cable Terminal Location
Figure 3-4 Cable Connector Terminals (SRC07GES, SRC03GES)
