Vertiv™ | Liebert® SRC-G | User Manual 37
Electrical Installation
Table 3-3 Indoor Unit Feed Terminal
Model PWM GND FAN FEED 1 FAN FEED 2 FAN FEED 3
SRC03GES Y Y Y NA NA
SRC07GES Y Y Y Y NA
SRC07GET Y Y Y Y NA
SRC11GET Y Y Y Y Y
The Full Load Current (FLA) of the indoor unit is given in Table 3-4.
Table 3-4 Full load current of the indoor + outdoor unit
Model Full Load Current (FLA)
SRC03GES 8 A
SRC07GES 20 A
SRC07GET 13 A
SRC11GET 17 A
Cut O the power supply to the unit prior to the maintenance, because the unit contains high voltage.
• Use copper cables only and ensure that all cables are firmly connected.
• Ensure that the power supply voltage is as per the voltage specified on the unit nameplate.
• Install a MCB switch before the power supply input of the indoor unit to easily isolate the unit for the
maintenance. Connect the power cable to the MCB switch and then to the unit.
• A RCCB should be installed before the indoor unit power supply input.
