Controller Operation Instructions
No. Description No. Description
1 LCD screen 3 Alarm indicator
2 Run state indicator 6 Control buttons
Figure 5-1 Microprocessor Controller Interface
5.3. Control Interface
5.3.1. Function Buttons
The microprocessor controller has five control buttons, as shown in Figure 5-2. The functions of these control
buttons are described in Table 5-1.
No. Description No. Description
1 On/O button 4 Up button
2 Enter button 5 Down button
3 ESC button
Figure 5-2 Control Buttons
