Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
136
Figure 63: EIB-1 and EIB-2 (Extended Interface Board) Connections
Schematic Diagram of EIB Board
J5-J9
Wire Size Capacity: 16-26 AWG.
Recommended Torque: 2.2 in-lbs.
EIB Board
MA455U41
EIB
SH1-
SH1+
SH2-
SH2+
SH3-
SH3+
J5
J6 J7
J8 J9
DCV1
DCV2
DCV3
DCV4
DCV5
DCV6
DCV7
D13_NC
DCV8
D13_COM
DO9_NC
D10_NC
DO9_COM
D10_COM
DO9_NO
D10_NO
D11_NC
D12_NC
D11_COM
D12_COM
D11_NO
D12_NO
J3 1 J3 2 J3 3 J4 1 J4 2 J4 3
2 4 3 1
J2
D13_NO
1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 12 3 4 5 6 1 23 4 5 6
SHUNT
INPUTS
VOLTAGE
INPUTS
RELAY OUTPUTS
EIB TEMP
PROBE 2
EIB TEMP
PROBE 1
