Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
183
Battery Connections to Optional Battery Busbar Extension Kit P/N 562364 (for system mounted in a
relay rack or enclosure)
DANGER! Adhere to the “Important Safety Instructions” presented at the front of this document.
Figure 108: Battery Connections to Optional Battery Busbar Extension Kit P/N 562364 (for system mounted in
a relay rack)
Battery
(Return Side)
Busbar
Battery
(Load Side)
Busbar
GND RTN
-48V SUPPLY
BATTERY BUSBAR
EXTENSION KIT P/N 562364
3/8” Clearance Holes
on 1” Centers
(Customer must supply
additional hardware)
Note: Central Office Ground
should be tied to any point
on the battery return busbar
or battery return extension
busbar.
List 24 Distribution Cabinet
(List 23 similar)
Front View
