Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
79
MAKING ELECTRICAL CONNECTIONS
Important Safety Instructions
DANGER! Adhere to the “Important Safety Instructions” presented at the front of this document.
Wiring Considerations
All wiring and branch circuit protection should follow the current edition of the American National Standards
Institute (ANSI) approved National Fire Protection Association's (NFPA) National Electrical Code (NEC), and
applicable local codes. For operation in countries where the NEC is not recognized, follow applicable codes.
For wire size, branch circuit protection, crimp lug, and general wiring recommendations; refer to System
Application Guide SAG582127000.
Lugs should be crimped per lug manufacturer’s specifications.
Refer to Table 5 for supplemental lug crimping information when using the special application crimp lug / strap
combination.
Table 5: Supplemental Lug Crimping Information when using the Special Application Crimp Lug / Strap
Combination
Crimp Lug Part No.
Crimp Tool Required
1
,
T&B Model TBM12 or TBM15 Hydraulic
Heads
Color Key
Die Index/
Code No.
Die Cat.
Number
245393500
Burndy:
YA25L-4TCG1
Pink 42H 15508
245393600
Burndy:
YA26L-4TCG1
Black 45 15526
245393700
Burndy:
YA27L-4TCG1
Orange 50 15530
245393800
Burndy:
YA28L-4TCG1
Purple 54H 15511
514872
T & B:
256-30695-
1879
Yellow 62 15510
Burndy:
YA29L-4TCG1
514873
T & B:
256-30695-
1880
Red 71 15514
Burndy:
YA31L-4TCG1
1
The lugs should be crimped to the specifications given in the manufacturer’s
instructions furnished with the crimp tool or lug.
