Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
70
Perform the following procedure to verify the factory settings. This procedure can also be used to make
adjustments on a replacement circuit card.
Procedure
1. Ensure SW1 is set per Table 1. Refer to Figure 33 for location.
Table 1:
IB2 Interface Board Switch Settings
Setting
DIP Switch SW1
1 2
IB2-1 in Main Bay
OFF
OFF
Optional IB2-2 in Main Bay ON OFF
Switch Setting on Optional EIB Interface Board (Main Bay Only)
Dip Switch SW1 on the EIB board is used to set the communications address for this board. Refer to Table 2 for
SW1 settings. Refer to Figure 34 for SW1 location.
Perform the following procedure to verify the factory settings. This procedure can also be used to make
adjustments on a replacement circuit card.
Procedure
1. Ensure SW1 is set per Table 2. Refer to Figure 34 for location.
Table 2:
Optional EIB Interface Board Switch Settings
Setting
DIP Switch SW1
1 2
EIB-1 in Main Bay OFF OFF
Optional EIB-2 in Main Bay
ON
OFF
