Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
187
Battery Connections to Optional Battery Landing Busbar Kit P/N 555478 (for system mounted in a relay
rack)
DANGER! Adhere to the “Important Safety Instructions” presented at the front of this document.
Figure 112: Battery Connections to Optional Battery Landing Busbar Kit P/N 555478 (for system mounted in a
relay rack)
1/4-20 x 0.875" Studs
on 0.625" Centers,
16 Places (Customer must
supply additional hardware.)
(Two Row Cabinet
Shown, Others Similar)
Rear View
GND RTN-48V SUPPLY
Plastic Shield
Up to Eight (8) Battery Leads (per polarity).
[Four (4) battery landing positions, two (2)
battery cable lugs back-to-back each position.]
Battery
(Return Side)
Busbar
Battery
(Load Side)
Busbar
