Figure 65: Controller Ethernet Port
NOTE! NCU ONLY: If your system has an IB4 board, DO NOT connect your Local Area Network (LAN)
to the NCU front Ethernet port. See “NCU Controller Second Ethernet Port Connection (if IB4 board
furnished)” on page 144.
ESC ENT
NCU
ACU+
10/100M Ethernet
Port (RJ-45)
10/100M Ethernet
Port (RJ-45)
ESC ENT
