Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
15
 Ethernet Connection Made (if required)
 Bay-to-Bay Cable Connections Made (as required)
 Bay-to-Bay Busbars Installed (as required)
 Bay-to-Bay Busbar Covers Installed (as required)
 Converter Output Cables (if furnished) Connections to +24VDC Distribution Made (as required)
 Load Connections Made
 Battery Connections Made
a) Batteries Installed and Connected in an optional Battery Tray (if furnished)
b) Optional Battery Tray Front Battery Covers Installed (if furnished)
c) Optional Battery Tray Circuit Breaker Guards Installed (if furnished)
Installing the Modules and Initially Starting the System
 Rectifier and Converter Modules Installed
 System Started, Configured, and Checked
