Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
27
Figure 6: Bolting Enclosures Together
Front of Cabinet
Already Installed
Side of Cabinet
Already Installed
Torque to 150 in-lbs.
Front of Cabinet
Being Added
Side of Cabinet
Being Added
5/16-18
Bolt
(3) 5/16”
Flat Washers
5/16”
Ground
Washer
Nut
5/16” Flat
Washer
5/16”
Nut
Mounting Hole
(one in each corner,
top and bottom)
