Vertiv NetSure 7100 Series Installation Manual

Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
31
Figure 9: Distribution Cabinet Mounting Hardware
3-ROW CABINET 4-ROW CABINET
1-ROW CABINET 2-ROW CABINET
Mounting Hardware,
4 Places per Side
Mounting Hardware,
6 Places per Side
Mounting Hardware,
8 Places per Side
Mounting Hardware,
5 Places per Side
MOUNTING HARDWARE
12-24 X 3/4" THREAD FORMING HEX HEAD SCREW
NO. 12 GROUND WASHER
Module Mounting Assembly not shown for clarity only.
