Figure 37: Relay Rack and Enclosure Frame Grounding Connection Points
Frame Ground
Connection Point
(1/4” clearance holes on 5/8” centers)
Frame Ground
Connection Point
(1/4” clearance holes on 5/8” centers)
Frame Ground
Connection Point
(1/4-20 Clinch Nuts on 5/8” centers)
Top View
(Typical Relay Rack)
Top View
(Typical Relay Rack)
Top View
(Typical Cabinet)
