Vertiv | NetSure 7100 Series -48V DC Power System Installation Manual (IM582127000) | Rev. BB
83
Direct AC Input Connections to the Module Mounting Assemblies
• The system can be equipped with module mounting assemblies that contain AC input terminal blocks
which provide a separate single phase AC input connection for each rectifier position (588705000 List
31; 588705500 List 03).
• The system can be equipped with module mounting assemblies that contain AC input terminal blocks
which provide a separate three phase AC input connection for every three (3) rectifier positions
(588705000 List 32 and List 33; 588705500 List 04 and List 05).
• The system can be equipped with module mounting assemblies that contain AC input line cords (one
for each rectifier module position) (588705000 List 22; 588705500 List 02).
• The system can be equipped with module mounting assemblies that contain AC input cable assemblies
or AC input line cords which provide a separate single phase AC input connection for every two (2)
rectifier positions (588705300 List 03).
• The system can be equipped with module mounting assemblies that contain AC input cable assemblies
or AC input line cords (one for each rectifier module position) (588705400 List 02).
• The system can be equipped with module mounting assemblies that contain AC input line cords which
provide a separate three phase AC input connection for every three (3) rectifier positions (588705400
List 03 and List 04).
AC Input Conduit Options (For System Mounted in an Enclosure)
Two types of conduit plates are available. Select and install the conduit plate appropriate for your application.
See “AC Input Conduit Options” on page 17.
