SAFE OPERATING INSTRUCTION
1. Hot Surface Warning Label
On the face of the motor [Fig. 4] you will find a Hot Surface warning label.
CAUTION Components can be hot after use or if exposed to high
temperatures.
2. Voltage Warning Label
This warning label is placed on the Battery and Controller cover [Fig. 4] of
your EVO.
The Controller for your EVO is attached to the rear of the Motor weldment
located just below the seat. The controller is not visible or accessible without
removing the controller cover. The label is placed on the end of the controller
cover. NOTE: English, Right side. French, Left side.
The battery is held in the battery compartment of your EVO. The warning
label is placed on the head portion of the battery, on the outer right side of
the charger connection port.
