VOLCON Grunt EVO - Troubleshooting

TECHNICAL INFORMATION
SPECIFICATIONS/TROUBLESHOOTING
Item
Standard
Troubleshooting
Charger
Charge Output
67.2v
Check the voltage switch
on the side of the
charger. Make sure it's
set to the appropriate
voltage for your region. -
If the small green LED
light does not come on
when the charger is
plugged into the power
outlet -Replace the
charger
Charge Current
10A
Charge Watts
670W
*Input Voltage
110V / 60Hz 220V /
50Hz
Model
C1200
Motor Controller
(ESC)
150A Continuous
60-72V
Check the display for any
alert codes.
Motor
25kw 60-72v
Check the display for any
alert codes
960-101086 Rev B Page 64 of 69
