VOLCON Grunt EVO - Page 66

TECHNICAL INFORMATION
SPECIFICATIONS/TROUBLESHOOTING
Item
Standard
Troubleshooting
D-pad
Directional Pad
Check to see if the
DC-DC converter is
working. Check and
make sure all pins are
seated in the VCU Plug.
Check to see all Pins are
seated correctly In the
White 30 Pin Connector
going into the Motor
Controller.
Headlight
LED with Halo P/N
Check to see if the
DC-DC converter is
working. Check fuses in
the fuse box
Tail light
LED Flex Strip
Check to see if the
DC-DC converter is
working. Check fuses in
the fuse box
Fuses
2x 7.5 fuse
Check Continuity
*Mexico and Canada operate on outlet voltages of 110V
to 127V and 60 Hz. The Volcon charger accommodates
this variation. Outside of North America, the charger will
support 220V and 50 Hz.
960-101086 Rev B Page 66 of 69
