Wacker Neuson ET18 - Page 113

OM ET18/20/24 us 1.3 * et18_20_24b510.fm 5-19
5
Increasing the width of the stabilizer blade
1. Raise the stabilizer blade to about 1 – 2 cm (about 0.39 – 0.79 in).
2. Pull out pins A on either side.
3. Turn out the stabilizer blade extensions B on either side.
4. Insert pins A on either side.
Fig. 145: Changing the width of the stabilizer
blade
A
B
