Wacker Neuson ET18 - Socket; Position of Socket; Swiveling Console Limit

4-28 OM ET18/20/24 us 1.3 * et18_20_24i400.fm
4
Socket
A 12 V socket is located at the front left of the machine chassis.
Swiveling console limit (option)
Limits the left-hand limit stop of the swiveling console for attachments with
a max. width of 800 mm (31 in) and prevents the attachment from
damaging the cab.
Notice
The limit stop can only be used for attachments with a max.
width of 800 mm (31 in).
Fig. 105: Position of socket
Fig. 106: Swiveling console limit
