OM ET18/20/24 us 1.3 * et18_20_24w700.fm 7-17
7
Removing/installing the cab/canopy
Accident hazard when traveling without cab/canopy!
Causes severe injury or death.
► Traveling with a removed cab/canopy is only allowed for
traveling very short distances.
► Fastening the seat belt is prohibited.
► Do not perform machine operation without a cab/canopy.
► Obtain the approval of the competent national authority.
► Machine travel is only allowed on level ground.
► Avoid tipping movements of the machine under all
circumstances.
► Traveling in areas involving a risk of falling objects is
prohibited.
Check for damage as you raise the machine.
► Slowly raise the cab.
► Wait until the machine does not swing any more.
► The lifting gear must not chafe or touch glass surfaces.
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Open the engine cover.
3. Remove shackle A in the engine compartment.
Fig. 232: Engine compartment shackle
A
