Proportional controls (option)
The proportional controls make it possible to adjust the movement speed
of the attachment. Moving the control lever slowly causes the attachment
to move slowly.
This control mode offers proportional operation of the auxiliary hydraulics
depending on the position of slide switch A on the control lever.
If precision machine operation (for example with an offset bucket) does
not require the full oil flow of the auxiliary hydraulics (AUX I and AUX II),
turn the rotary switch to the left (MIN).
If the full oil flow is required, turn the rotary switch to the right (MAX).
A
Fig. 149: Control lever for proportional controls
Fig. 150: Rotary switch on left-hand control lever
base
Fig. 151: Rotary switch on right-hand control
lever base
