Wacker Neuson ET18 - Introduction; Machine Overview

OM ET18/20/24 us 1.3 * et18_20_24e300.fm 3-1
3
3Introduction
3.1 Machine overview
Fig. 3: Machine overview
Position Designation
1. Working light on boom
2.
Roof lights (option)
3.
Lifting eye
4.
Rotating beacon (option)
5.
Door arrester
6.
Engine cover
7.
Fuel tank filler inlet
8.
Side cover
9.
Exhaust pipe
10.
Eye hook for tying down the machine
11.
Stabilizer blade
12.
Travel gear
13.
Handle
14.
Auxiliary hydraulics
15.
Door handle and lock
2
12
1
6
13
11
10
15
2
8
4
5
9
14
10
2
3
3
13
8
10
10
7
