7.9 Cooling system
Information regarding the cooling system
The oil/water radiator is located behind the right-hand cover, on the right
side of the engine. It cools the diesel engine, and the hydraulic oil of the
travel and work hydraulics.
In order to avoid damage to the engine and radiator.
► Observe the fluids and lubricants table, and the coolant
compound table.
► Check the coolant level once a day.
Checking the coolant level
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Open the engine cover.
3. Check the coolant level on sight glass A.
4. If the coolant level is below the FULL mark:
➥ Add coolant.
5. Close and lock the engine cover.
Check the coolant level once a day.
We recommend checking it before starting the engine.
Observe the coolant compound table.
Fig. 250: Checking the coolant level
A
FULL
