Wacker Neuson ET18 - Lower Mounting Point; Upper Mounting Point on Machine; Lower Mounting Point on Machine

4-24 OM ET18/20/24 us 1.3 * et18_20_24i400.fm
4
6. Mounting point for cab/canopy: B (upper)/D (lower)
7. Tighten screws F (M12/10.9) and lock nuts on the left and right to 110
Nm (87 ft.lbs).
8. Install the mirrors in both positions E.
Fig. 96: Lower mounting point
F
Fig. 97: Upper mounting point on machine
B
Fig. 98: Lower mounting point on machine
D
