ET24 – VDS, canopy, boom uphill
ET24 – VDS, canopy, boom downhill
3.5 m (11'-6") 3.0 m (9'-10") 2.5 m (98 in) 2.0 m (79 in)
Short stick Long stick Short stick
Long
stick
Short
stick
Long stick Short stick Long stick Short stick Long stick
2.5 m
(98 in)
384
(847)
345
(761)
--
426
(939)
426
(939)
535
(1180)
459
(1011)
--
2.0 m
(79 in)
345
(761)
313
(690)
-
327
(721)
420
(926)
418
(922)
554
(1221)
546
(1204)
713
(1572)
-
1.0 m
(39 in)
318
(701)
290
(639)
322
(710)
317
(699)
401
(884)
397
(875)
518
(1142)
515
(1135)
711
(1568)
712
(1570)
0.0 m
(0.0 in)
344
(758)
309
(681)
-
310
(683)
390
(860)
382
(842)
500
(1102)
491
(1083)
689
(1519)
678
(1495)
−1.0 m
(−39 in)
486
(1072)
413
(911)
----
509
(1122)
495
(1091)
701
(1545)
685
(1510)
−1.5 m
(−59 in)
609
(1343)
596
(1314)
---- - -
485
(1069)
703
(1550)
3.5 m (11'-6") 3.0 m (9'-10") 2.5 m (98 in) 2.0 m (79 in)
Short stick Long stick Short stick
Long
stick
Short
stick
Long stick Short stick Long stick Short stick Long stick
2.5 m
(98 in)
287
(633)
255
(562)
--
319
(703)
319
(703)
428
(944)
429
(946)
--
2.0 m
(79 in)
256
(564)
230
(507)
-
241
(531)
314
(692)
312
(688)
415
(915)
416
(917)
583
(1285)
-
1.0 m
(39 in)
233
(514)
210
(463)
236
(520)
231
(509)
295
(650)
291
(642)
381
(840)
378
(833)
516
(1138)
516
(1138)
0.0 m
(0.0 in)
252
(556)
224
(494)
-
224
(494)
285
(628)
276
(609)
363
(800)
355
(783)
496
(1094)
485
(1069)
−1.0 m
(−39 in)
356
(785)
300
(661)
----
372
(820)
358
(789)
507
(1118)
491
(1083)
−1.5 m
(−59 in)
597
(1316)
434
(957)
---- - -
485
(1069)
508
(1120)
