7 Maintenance
Operator seat
Folding the operator seat forwards
1. Pull handle A and push operator seat fully backwards.
2. Unscrew the 3 hexagon screws B on each side of the operator seat.
3. Fold the operator seat forward and secure against falling back,
e.g. with a seat belt on the steering column (see fig.).
