BA 357-00 * 3.0 * 35700_09_Technische_Daten.fm 9-7
Technical data 9
9.7 Operating hydraulics
Operating motor
Hydraulic oil reservoir
Hydraulic pump
Pilot control
Designation
Product Jungheinrich
Type AP4H6-L3
Design
3-phase alternating current
asynchronous motor
Housing protection IP 54
max. operating voltage /
current rating
43 V/380 A
Power
22 kW S3-15% (29.9 hp)
at 2560 min
-1
Max. torque
200 Nm (147.5 ft lb)
LS 1200 min
-1
Max. engine speed without load 3000 rpm
Designation
Volume About 40 l (8.8 gal)
Return suction filter 0.5 bar (7.15 psi) pre-tension
Designation
Hydraulic pump Gear pump
Displacement
19 cm
3
/rev. 54 l/min
(1.16 in
3
/rev. 14.26 gpm) 3000 min
-1
Max. operating pressure
1
1. Measured on the pump
235 5bar (3408 72.5 psi)
Designation
Operating principle Mechanical
Control valve (3-fold)
Operation: raise/lower with joystick,
Operation: 3rd control circuit with control
lever or rocker switch on joystick (option)
Return suction filter 0.5 bar (7.15 psi) pre-tension
