4 Putting into operation
Description of the indicator and warning lights in the gauge
Warning light (yellow) – error
The warning light 38 illuminates if the machine electronics
report an error during operation.
➥ An uninterrupted warning signal sounds for approx. 3 seconds.
➥ An error message is displayed for 3 seconds in the digital
display 45 in area F as error code. The error can be queried,
immediately or later on, in the display – see chapter 8 “Error display
of machine electronics in gauge” on page 8-3.
➥ Turn off the machine and then turn it on again. If no error code is
displayed any more in the display, the machine can continue to be
operated.
Warning light (red) – error "STOP"
The warning light 39 illuminates if the machine
electronics report a critical error during operation.
➥ A steady warning signal sounds.
➥ In the digital display, 45in areas B and C, the symbol 5 appears.
➥ An error message is displayed in the digital display 45 in area F as
error code. The error can be queried, immediately or later on, in the
display.– see chapter 8 “Error display of machine electronics in
gauge” on page 8-3
➥ If the error is displayed, contact an authorized service center.
► The error message must be confirmed. The means the warning signal,
the warning light and the display symbol only go out if one of both
buttons 46 or 47 are pressed in the gauge.
Indicator light (green) – right/left-hand turn indicators
The indicator light 40 flashes periodically if the turn indicator is actuated
– see "Turn indicators" on page 5-21.
Warning light (red) – parking brake
The warning light 41 flashes if the parking brake was enabled
automatically and illuminates if the parking brake is enabled manually
– see chapter 5 “Parking brake” on page 5-6.
