BA 357-00 * 3.0 * 35700_09_Technische_Daten.fm 9-3
Technical data 9
9.3 Travel drive/axles
Hydraulic motor
Transfer gearbox
Travel drive
Designation
Product Juli Motorenwerk
Type AF 4/7-R1
Design
3-phase alternating current asynchronous
motor
Housing protection IP 54
max. operating voltage /
current rating
48 V/226 A
Power
15 kW S 2-60 minn (20.4 hp)
at 2110 min
-1
(maximal 34 kW (46.2 hp))
Max. torque 220 Nm (162.3 ft lb)
Max. engine speed without
load
6000 rpm
-1
Designation
Product Schmahl ZSB I2
Design Single-stage
Designation
“Turtle” speed range 7 km/h (4.3 mph)
"Hare" speed range 17 km/h (10.6 mph)
Traction force
1
1. Standard tires 12.0-18
26 kN (5845 lbf)
