BA 357-00 * 3.0 * 35700_05_Bedienung.fm 5-5
Operation 5
5.3 Brake
Service brake
Accident hazard due to blocked or dirty pedal!
Can cause serious injury or death.
► Keep the brake pedal clean and do not deposit any objects in the area
of the pedal.
Accident hazard when moving down a slope too fast!
Can cause serious injury or death. Excessive speed can damage the
travel drive, brakes and electric motor.
► Select the next lower speed range before performing downhill
machine travel.
► Reduce engine speed: remove your foot from the accelerator pedal.
► Reduce the travel speed with the brake pedal (intermittent braking).
Brake pedal 32 is located on the left in the cabin.
Check brake
1. After looking in the rear-view mirror and at low speed, press down the
brake pedal and check the braking effect.
➥ The brake lights must illuminate.
Braking with the brake pedal
1. Actuate the brake pedal.
➥ The brake lights illuminate.
