3-4 BA 357-00 * 3.0 * 35700_03_Einleitung.fm
3 Introduction
3.2 Brief description of the machine
Main components of the machine
• Stable sheet steel frame accepting main components
• ROPS/FOPS tested cabin (roll-over/falling object protection);
Category I Series, Category II option)
– see chapter 4 “Cabin/control stand” on page 4-1
- ROPS is the abbreviation for the English concept "Roll Over
Protective Structure"
- FOPS is the abbreviation for the English concept "Falling Object
Protective Structure"
• Travelling drive:
- Alternating current electric motor (hydraulic motor),
asynchronous; flange-mounted to the transfer gearbox;
supported on oscillating element
- Single-stage transfer gearbox
- Maximum speed 17 km/h (10.6 mph)
• Work hydraulics:
- Alternating current electric motor (operating motor), asynchronous;
supported on oscillating element
- Hydraulic pump (gear pump); Speed-controlled volumetric flow
• Hydraulic four-wheel power steering with emergency steering features
• Planetary steering axles front and rear; rear oscillating design,
front with differential lock
• Operating brake (brake-disc on front axle drive shaft);
Braking effect is transferred via the cardan shaft to the rear axle)
• Parking brake
(spring-applied brake; acting on motor shaft (hydraulic motor))
The machine is equipped with an operator presence switch to protect the
operator. In this case:
• The machine can only be switched on if the operator has taken his
place in the operator seat.
• If the operator seat is relinquished for more than 3 seconds during
machine travel, the machine is braked until it comes to a standstill and
the parking brake engaged once in standstill.
The machine can be equipped with the “Telematics”
option (transmission of operational data, location, etc. via satellite)!
Please contact your dealer if you require
information on the “Telematics” option.
