BA 357-00 * 3.0 * 35700_07_Wartung.fm 7-71
Maintenance 7
Cleaning/replacing the fine-dust filter of the cabin ventilation
Observe the maintenance intervals
– see "Maintenance plan" on page 7-6.
Replace the fine-dust filter every 500 o/h (operating hours) by a new one.
The fine=dust filter is located in the leg room on the left in travel direction
behind trim A.
1. Remove fastening screws on the trim A to the left and right (Allen
key 3 mm / 0.1 in).
2. Pull away trim A a little.
3. Remove fine-dust filter B and check it for damage.
4. Knock dust filter B on either side on a plate, or clean it with
compressed air, or wash it with water and allow it to dry.
➥ Replace or clean the filter more frequently if the machine is used in
severe dust conditions.
5. Insert fine-dust filter B
6. Install trim A.
In order to ensure dust-free air inside the cabin, pay attention to the
correct position of filter B as you insert it.
