BA 357-00 * 3.0 * 35700_07_Wartung.fm 7-83
Maintenance 7
Cleaning the heat exchanger (condenser)
Risk of injury due to hot parts!
Touching hot components can result in injury.
► Allow the machine to cool down.
► Wear protective equipment.
1. Apply the parking brake.
2. Turn the machine off and remove the ignition key.
3. Remove cover A from the protective screen.
4. Clean heat exchanger C with a water jet
(do not use a high-pressure cleaner or compressed air).
5. Clean the air-intake area at the protective screen.
6. Install the cover A.
Dehumidifier B has to be replaced
every 2 years by an authorized service center.
