Wacker Neuson KRAMER 5055e User Manual

BA 357-00 * 3.0 * 35700_09_Technische_Daten.fm 9-19
Technical data 9
Machine with pallet fork (KRAMER quickhitch)
B
C
Fig. 275
A
Designation
1,2
1. Applies to pallet forks 1000237357 (see load diagram)
2. Loader unit in horizontal position, 500 mm (19.68 in) load distance
S = standard
loader unit
L = extended
loader unit
Payload
safety factor 1.25 (A)
1750 kg
(3858 lb)
1600 kg
(3528 lb)
Payload
safety factor 1.67 (B)
1310 kg
(2889 lb)
1200 kg
(2646 lb)
Movable payload
3
Transport position:
Safety factor 1.25 (A)
3. The movable payload is only authorized in transport position of the loader unit,
and is not specified in the load diagram.
2000 kg
(4409 lb)
1850 kg
(4078 lb)
Movable payload
3
Transport position:
Safety factor 1.67 (B)
1500 kg
(3307 lb)
1400 kg
(3087 lb)
