Appendix VI—CE Racked Assembly LTN Assembly
wc_tx001217gb.fm 112
Connecting
the wires
6. Refer to the table below and connect the light fixture wires to the coil cord wires.
Use the small connectors and Panduit wire crimper CT-100.
7. Connect the green wires from the fixture cords and coil cord, along with the
green/yellow ground wire, using the large connector and Panduit wire crimper
CT-1500.
8. Install the ring terminal on the ground wire to the ground screw (FF) in the
junction box.
Position Light wire Coil cord wire
L1 Black Red
White Orange
Green —
L2 Black Black
White Brown
Green —
L3 Black Yellow
White White
Green —
L4 Black Blue
White Purple
Green —
To Next Page
