LTN 6L Operation
wc_tx000766gb.fm 33
4.3 Adjusting Lights
See Graphic: wc_gr005074
Each light fixture can be aimed up, down, left or right. Position each
fixture by loosening toolless light adjusters (g) and aiming the light up
or down. DO NOT loosen the inside nut (x). Loosening this nut could
cause damage to the light fixture. Loosen the nut (h) to turn light
fixtures left or right. Tighten adjusters and nuts after positioning the
lights.
Always return the light fixtures to aim at the ground when the tower is
in the cradle for towing.
