Operation LTN 6L
32 wc_tx000766gb.fm
4.2 Leveling Trailer
See Graphic: wc_gr005073, wc_gr005074
The trailer must be leveled and the outriggers extended before raising
the tower. The outriggers must remain extended while the tower is up.
Failure to level the trailer or extend the outriggers will severely reduce
the stability of the unit and could allow the tower to tip and fall.
4.2.1 Pull the locking pin on the tongue jack (a) and rotate the tongue jack
90° as shown.
Block or chock the trailer wheels (b). Crank the tongue jack down to
raise the trailer tongue off the vehicle.
4.2.2 Pull the outrigger lock pin (c) to release the outrigger. Pull both
outrigger extensions (d) out until you feel outrigger lock pin lock back
into place. Rotate jacks (e) down.
4.2.3 Rotate rear jack (f) down, as shown.
4.2.4 Extend the jack(s) on the highest side(s) of the trailer until they rest
firmly on the ground. Extend the remaining jacks until the trailer is
level.
WARNING
