LTN Appendix V—Standard Racked Assembly
wc_tx001216gb.fm 83
13 Appendix V—Standard Racked Assembly
Overview
This set of assembly instructions applies to standard machines shipped on a
container rack as shown below.
If your machine does not look like the one shown in the illustration, refer to Machine
Identification in the Introduction chapter to identify the appropriate set of assembly
instructions.
Tasks
To complete the assembly of your Light Tower, the following tasks must be
performed in the order listed:
wc_gr006469
Task Description See topic
Chassis assembly
1 Install the axle 13.1
2 Install the fenders 13.2
3 Install the wheels 13.3
4 Install the outriggers and outrigger jacks 13.4
5 Install the rear jack 13.5
6 Install the tongue assembly 13.6
Tower assembly
7 Install the tower lock bracket 13.7
8 Install the tower cradle 13.8
9 Install the tower 13.9
10 Install the tower pivot cable 13.10
Lights assembly
11 Install the lights 13.11
Electrical assembly
12 Wire the junction box 13.12
13 Route the coil cord 13.13
14 Wire the ballasts and terminal strips 13.14
