LTN 6L Labels
wc_si000381gb.fm 27
T
Power Winch System
To lower tower:
1. Turn off all lights and engine.
2. Rotate tower and tighten knob.
3. Lower tower using winch.
To tilt tower for transport:
4. Release and hold spring-loaded pin.
5. Tilt tower using winch.
To secure tower for transport:
6. Insert pin through transport lock and secure
with pin.
7. Position light fixtures down.
U
Coolant overflow bottle only, not a return system.
V
WARNING!
Pinching hazard. Rotating machinery.
