4.5.4 Continue to rotate the winch handle and raise the tower to the vertical
position until the vertical tower locking pin (p) locks the tower in place.
Be certain the vertical tower locking pin is fully engaged in the locking
position before raising the tower.
NOTICE: While raising the tower, pay close attention to the coil cord
and make sure that it does not tangle or become caught on any part of
the machine.
NEVER pull the vertical tower locking pin (p) while the tower is
raised! Releasing the vertical tower locking pin while the tower is
raised may cause the tower to fall or the machine to tip over.
4.5.5 After the tower is in the vertical position, check the operation of the
telescoping winch (q) by rotating the winch handle 1/4-turn clockwise
(“cable in” direction). The winch pawl must engage winch gear teeth.
When operating properly, it will make a “clicking” sound when the
winch handle is rotated clockwise. Do not attempt to raise the tower if
the winch is damaged or not operating properly. Continue rotating the
winch handle until tower is at the desired height. Do not over crank the
winch when the tower is fully extended.
NOTICE: Do not extend the tower beyond the red marking on the
tower!
4.5.6 Once the tower is at the desired height, rotate the tower to the desired
direction. To rotate, loosen rotation locking knob (s). Then rotate the
tower until the lights face the desired direction, and then retighten the
rotation locking knob.
WARNING
