LTN 6L Operation
wc_tx000766gb.fm 39
4.6.4 Pull and hold the tower locking pin (p). Rotate the handle on the tilt
winch (o) counterclockwise (“cable out” direction) until the tower spring
begins to pivot the tower down. Release the tower locking pin and
continue to rotate the handle until the tower is resting in the transport
cradle. Be sure that the secondary locking pin (t) penetrates all
sections of the tower.
NEVER pull the vertical tower locking pin (e) while the tower is
raised! Releasing the locking pin while the tower is raised may cause
the tower to fall or the machine to tip over.
4.6.5 After the tower is down, secure it in the cradle by inserting the cradle
lock pin (j). Insert the clip through the pin to secure it in place.
4.6.6 Position the light fixtures to aim at the ground.
NOTICE: Allow the floodlights to cool 10–15 minutes before moving
trailer. Moving the trailer while the lights are still hot could cause the
lamps to break.
WARNING
