LTN 6L Operation
wc_tx000766gb.fm 41
4.7.5 After the tower is in the vertical position, check the operation of the
telescoping winch (q). Turn the telescope rotary switch on the control
panel to the up position. Do not attempt to raise the tower if the winch
is damaged or not operating properly. Continue to hold switch in the up
position until tower is at the desired height. Release switch when tower
is fully extended.
NOTICE: Continuous running of the winch in excess of 4 minutes will
damage the winch motor.
NOTICE: Do not extend tower beyond red marking on tower!
4.7.6 Once the tower is at the desired height, rotate the tower to the desired
direction. To rotate, loosen rotation locking knob (s). Then rotate the
tower until the lights face the desired direction and retighten the
rotation locking knob.
