Operating manual Powder Cup Gun PEM-X1 CG
5 Description
Order number 2326960 | Edition 10/2022 19
5.3 EXTENT OF DELIVERY
Stk Order no. Designation
1 2322588 PEM-X1 CG powder cup gun
-- Nozzle set
The standard equipment includes:
1 2326024 Declaration of Conformity
1 2326959 Operating manual, in German
1 see Chapter Languages [87] Operating manual in local language
5.4 DATA
5.4.1 Technical Data
Dimensions:
Length/width/height see Chapter Dimensions
[820]
Weight 550 g; 1.21 lbs
Cup capacity 130 g; 0.29 lbs
Cup filling volume 210 cm
3
; 7.93 ci
Electrical:
Input voltage maximum 22 Vpp
Input current maximum 0.9A
Frequency 19–30 kHz
Output voltage maximum 100 kV DC
Maximum Corona current 120 µA
Polarity negative / positive (special ac-
cessories)
Pneumatic:
Input air pressure (atomizing air volume) maximum 3 bar; 0.3 MPa, 43.51
psi
Powder discharge quantity maximum 200 g/min; maximum
0.44 lbs/min
WARNING
Exhaust air containing oil!
Risk of poisoning if inhaled.
4 Provide compressed air free from oil and water.
Ambient conditions:
When using low-melting powder varieties, an ambient temperature below 30°C (86°F) may
be necessary.
Volume specifications for volumes that are specified in Nm
3
(normal cubic meters). One
cubic meter of gas at 0°C and 1.013bar is referred to as a normal cubic meter.
