WAGNER PEM-X1 Translation Of The Original Operating Manual

Operating manual Powder Cup Gun PEM-X1 CG
8 Cleaning and Maintenance
32 Order number 2326960 | Edition 10/2022
8.3 CHANGING THE CUP GUN
Before replacing the spray gun, any powder residue must be thoroughly removed.
The wearing parts in the spray gun, marked in the spare parts list with ♦, must be regularly
checked and replaced if necessary.
6
4
5
2
1
P_01732
3
1. Switch off control unit.
2. Disconnect electrical cable 1 from control unit 2.
3. Disconnect dosing air hose 3, feed air hose 4 and atomizing air hose 5 from spray gun 6.
4. Connect dosing air hose 3, feed air hose 4 and atomizing air hose 5 to new spray gun 6.
5. Connect electrical cable 1 to control unit 2.
6. Switch on the control unit.
7. The spray gun is ready for use again.
