SPEEDGATE Installation and Maintenance Manual Revision 1 - MAY 2023
27
SAFETY DEVICES
Table 2. Inherent Entrapment Sensor (IES) Shutdown Modes
1
“So shutdown” mode: In order to restore gate operaon, a renewed open or close command must
be given.
A normal command to operate the gate (open signal, card reader, close signal, vehicle presence on an
Automac Exit Loop) will return the Gate to operaon. The auto close mer will not be funconal unl
such a signal is received. This status is commonly referred to as a “So Shutdown” mode.
2
“Hard shutdown” mode. In order to restore gate operaon, the system must be manually reset by
opening the operator cabinet door to access the panel and pressing and holding the stop buon on the
foil keypad (up arrow, down arrow, stop buon) located to the right of the LCD display; i.e., hold to clear.
Following a Hard Shutdown, and prior to reseng the system, it is the sole responsibility of the user
to ensure the area is free of obstrucons and that it is safe to operate the Gate.
When an obstrucon is encountered the rst me in a gate cycle, F320 will appear
on the LCD display if the gate shuts down while traveling in the open direcon; F325
for the close direcon. F395 will appear on the display if a second entrapment trip
occurs in the same cycle (hard shutdown via the inherent reduced speed sensor/
torque change sensor).
If gate operaon is not restored with a normal command (open signal, card
reader, close signal, vehicle presence on an Automac Exit Loop) or, in the case of
a hard shutdown, a system reset, check the controller LCD display for addional
troubleshoong error codes.
The prescribed soluon will vary, depending on the display number indicated. When
the fault or error is resolved, a normal command for a new open or close cycle will
restore gate operaon. Otherwise, the issue could be with the gate operator or
another gate component.
ORIGINAL GATE
POSITION
Obstacle
Encountered,
Acvang the
IES
Gate Response System Mode
Opening Yes Gate should reverse to closed posion
and wait for a renewed command.
--
